Main Specifications Working conditions

This type of product is an electronic power device capable of fast switching of power shunt capacitors. Its electrical structure is mainly composed of high power anti-parallel.Thyristor module, isolation device, trigger circuit, synchronization circuit, protection circuit and driving device, and equipped with control to grow or turn on or off Terminal, control logic voltage 0V (off), 12V (on). The switch has the advantages of simple installation, convenient maintenance, fast response, no flow and no flow.The non-noise field of the work is stable and reliable, and the phase loss protection is the ideal device for the reactive power dynamic compensation device with the switching capacitor.



Working conditions
Ambient air temperature: -25℃~+50℃, and its average temperature within 24 h is not higher than +30℃; When the temperature is +25℃, the relative humidity is ≤90%;
The altitude does not exceed 2000m;
The installation site is clean, free from explosions and flammable dangerous goods, and does not have enough gas to damage the insulation and corrosion. There is no conductive dust and serious mold in Egypt;
There is no obvious over-harmonic harmonic content in the installation site.
